Applicable to: 8-inch disc

Capacity: 25 pieces/slot, can be designed according to customer production capacity requirements

Beat: 0-99min adjustable

Equipment skeleton: SUS304 is wrapped with 3mm PP-W, and the shell is welded with imported 2mm thick SUS304 mirror panel

Degumming cleaning tank: 2mm thick SUS316L mirror panel bending welding and electrolytic polishing

QDR groove: imported from Germany, made of 10mm PP-N plate by hot melt welding

Equipment features:

1. Adopting Delta touch screen human-machine interface operation and Mitsubishi PLC control

2. Using corrosion-resistant wires and protected by corrosion-resistant PE pipes, corrosion-resistant and waterproof

3. Install a 3mm thick PP leak proof tray at the bottom of the equipment to effectively prevent equipment leakage from damaging the factory floor

4. After the user operator loads the material, the entire process is automatically controlled, reducing manual intervention, achieving high automation, low operating costs, high production efficiency, stable performance, and safety and reliability

5. High safety performance of the equipment: The equipment has been strictly designed in terms of anti leakage, heating, and leakage, ensuring personal and factory safety
